Easy To Operate Automatic Mobile Robot Pallet Stretch Film Wrapper Packing Wrapping Machine(2.4m Max Wrapping Height) 555018
(0
reviews)
Sold by:
Inhouse product
Inhouse product
Price:
$3,780.00
/pc
Refund:
Share:
Top Selling Products
Product Description
Mobile robot pallet wrapper is belong to a movable machine that with two rechargeable batteries. After the battery is fully charged, the mobile robot pallet wrapper can work continuously for 8 hours. It is suitable for heavy goods or special shaped pallets. The pallet is stationary on the ground. The mobile robot pallet wrapper automatically rotates 360 degrees around the pallet to automatically detect the height of goods. The wrapping height of the standard machine can reach 2.4m and the maximum customized height can reach 2.8m. The mobile robot pallet wrapper adopts PLC control system, and the performance of the whole machine is stable.
Machine Features:
1.Adopt movable power, can be continuous used 8 hours.
1.Adopt movable power, can be continuous used 8 hours.
2.Photoelectric detect pallet height up 2.4m.
3.Rotating speed adjustable,accurate resetting after wrapped.
4.Die carrier up and down speed can be adjustable.
5.There has emergency switch in front of the machine to avoid run into the wrapping.
6.PLC control system will be more stable
7. Wrapping number of turns can be setting, bottom:adjustable 1-12 turns; up: adjustable1-12turns.
3.Rotating speed adjustable,accurate resetting after wrapped.
4.Die carrier up and down speed can be adjustable.
5.There has emergency switch in front of the machine to avoid run into the wrapping.
6.PLC control system will be more stable
7. Wrapping number of turns can be setting, bottom:adjustable 1-12 turns; up: adjustable1-12turns.
Specification
Model | XT-4510 |
H.S code | 8422400090 |
Min pallet size | L600*W600*H500mm |
Max pallet length&wide | Unlimit |
Wrapping height(standard machine) | 2400mm(2800mm and 3200mm customized) |
Control panel | Touch screen(english language) |
Control system | PLC |
Max moving speed | 70m/min |
Charge power | AC100-240V 1Phase 50/60Hz |
Required charge time | 8-10hours |
Rated working time | 8hours |
Wrapping layers | 1-12set |
Power | 0.95kw (Rotating motor 0.4kw /Up/down motor 0.35kw / Pre-stretch motor 0.2kw) |
Stretch film specification | wide 500mm,thickness 20-30mic,inner diameter 76mm |
Machine size | L1583*W1233*H2800mm |
Machine weight | 410kg |
Wooden case size | L2700*W1000*H1240mm |
G.W | 450kg |
Details Images
Related Products
Packing&Delivery
Q1:What is the MOQ if we place an order?
A1:MOQ 1set.
Q2:Custom made service is available?
A2:Yes,we can custom made the wrapping height that max up to 2800mm.
Q3:How many days of the lead time for standard machine?
A3:15-20workdays after received the payment.
Q4:How long time of your warranty period?
A4:12months since received the machine.
Q5:How to fix the problems if equipments got fault in working?
A5:take a video to us first,we will check and let you know how to do.we will send new spare parts to you if needs.
Q6:If the machine approved CE certificated?
A6:Yes,our machine had approved CE certificate.
Q2:Custom made service is available?
A2:Yes,we can custom made the wrapping height that max up to 2800mm.
Q3:How many days of the lead time for standard machine?
A3:15-20workdays after received the payment.
Q4:How long time of your warranty period?
A4:12months since received the machine.
Q5:How to fix the problems if equipments got fault in working?
A5:take a video to us first,we will check and let you know how to do.we will send new spare parts to you if needs.
Q6:If the machine approved CE certificated?
A6:Yes,our machine had approved CE certificate.
