15kw diesel generator 15kva 3phase backup generator diesel power genset 555013
(0
reviews)
Sold by:
Inhouse product
Inhouse product
Price:
$1,590.00
/pc
Refund:
Share:
Top Selling Products
Product Description
Specification
Model | KT2500L(E) | KT3500L(E) | KT6500L(E) | KT7500L(E) | KT10000L(E) | KT15000L(E) | |||||
Frequency(HZ) | 50/60 | 50 | |||||||||
Rated output(kva) | 1.8/2.0 | 2.8/3.0 | 4.5/5.0 | 5.0/5.5 | 6.0/6.5 | 8.5 | |||||
Max. output(kva) | 2.0/2.2 | 3.0/3.2 | 5.0/5.5 | 5.5/6.0 | 6.6/7.2 | 9.3 | |||||
Rated. AC voltage(v) | 110,220,230,120/240, 220/380 | ||||||||||
Rated current(A) | 7.4 | 12.2 | 19.6 | 21.7 | 28.2 | 36.9 | |||||
Rated rotation speed(r/min) | 3000/3600 | 3000 | |||||||||
Phase No. | Single/Three phase | ||||||||||
Power factor(cosΦ ) | 1/0.8 | ||||||||||
Excitation mode | Self-excitation & constant voltage (AVR) | ||||||||||
Overall dimension (LXWXH) (mm) | 640*480*530 | 655*480*530 | 720*492*655 | 178*585*710 | |||||||
Dry weight(kg) | 53 | 70 | 100 | 130 | |||||||
Operating noise level(at 7m)(dB(A)) | 77 | ||||||||||
Structure type | open type | ||||||||||
Engine Model | KT173 | KT178F | KT186FA | KT188F | KT192F | KT1100F | |||||
Engine Type | Single-cylinder, vertical, 4-stroke, direct injection, air-cooled | ||||||||||
Bore× stroke (mm) | 70X55 | 78x62 | 86X72 | 88X75 | 92x75 | 100x85 | |||||
Displacement (ml) | 211 | 296 | 418 | 456 | 498 | 667 | |||||
Rated Power | 2.5/3000 2.8/3600 | 3.68/3000 4/3600 | 5.7/3000 6.3/3600 | 6.5/3000 7.2/3600 | 7.6/3000 8.2/3600 | 10.5/3000 | |||||
Compression ratio | 20:01 | 19:01 | 20:01 | ||||||||
Starting system | Recoil + Electric starter | Electric starter | |||||||||
Fuel type | 0# (summer) -10# (winter)-35# (chillness) diesel | ||||||||||
Lube oil brand | CD grade or SAE10W-30, 15W-40 | ||||||||||
Continuous running time (hr) | 14 | 8.5 | 5.5 | 5 | |||||||
Rated output(kva) | 7500W/9000W | 11000W | 14500W | ||
Max. output(kva) | 8000W/10000W | 12000W | 15000W | ||
Rated. AC voltage(v) | 220V Single Phase; 380V Three Phase | ||||
Rated current(A) | 36A/12A 45A/26A | 54A/31A | 68A/39A | ||
Operating noise level(at 7m)(dB(A)) | 65dB 85dB | 65dB 88dB | 68dB 95dB | ||
Displacement (ml) | 498cc | 668cc | 712cc | ||
Engine Type | Single cylinder vertical direct injection four stroke | ||||
Frequency(HZ) | 50Hz | ||||
Fuel Consumption | 2.15L | 1.6L | 2.15L | ||
Fuel Tank Capacity | 16L | 20L | 20L | ||
Oil Capacity | 1.6L | 1.6L | 1.8L | ||
aMotor Type | all copper quality brushed motor | ||||
Dry Weight | 165kg; 118kg | 245kg 155kg | 260kg 165kg | ||
